Hot Rolled SAE4140 Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod

Hot Rolled SAE4140  Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod
Hot Rolled SAE4140  Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod Hot Rolled SAE4140  Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod Hot Rolled SAE4140  Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod

Büyük resim :  Hot Rolled SAE4140 Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod

Ürün ayrıntıları:
Menşe yeri: Çin
Marka adı: TSING SHAN
Sertifika: SGS ISO MTC
Model numarası: AISI 4140
Ödeme & teslimat koşulları:
Min sipariş miktarı: 100kgs
Fiyat: 0.65-0.95 USD/KG
Ambalaj bilgileri: İhracat ambalajı
Teslim süresi: 7 gün
Ödeme koşulları: L/C, T/T
Yetenek temini: 50000KGS

Hot Rolled SAE4140 Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod

Açıklama
Teknoloji: Sıcak Haddelenmiş Taşıma paketi: Dışa aktarma Standart Paketi/Talep Olarak
Özel yapılmış: Evet Fiziksel Özellikler: Özgül Ağırlık 7.85
Boyutlar: 16-400mm Mekanik Özellikler: Standart olarak
Model Hayır: 4140 Teknik: Sıcak Haddelenmiş
İşlenebilirlik: İyi İkincil veya değil: ikincil olmayan
Hizmet vermek: Kesme Son: Eğimli/Düz
HS kodu: 7312000 Kaynak: Geleneksel yöntemler

Hot Rolled SAE4140 Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod







1: AISI 4140 steel introduction
AISI 4140 is defined as a low alloy steel which has 1% Cr-Mo as strengthening alloy elements.Compared with AISI 4130, it has a higher carbon content with good balance of strength, toughness ,abrasion and impact resistance and heat treatment capabilities,but poor in weldability characteristics.AISI 4140 is generally supplied in quenched and tempered condition with hardness 28-32HRC

2: AISI 4140 Steel equivalent

Country China Japan Germany USA British
Standard GB/T 3077 JIS G4105 DIN (W-Nr.)
EN 10250
AISI/ASTM
ASTM A29
BS 970
Grade 42CrMo SCM440 42crmo4/1.7225 4140 EN19/709M40

3: AISI 4140 steel chemical composition
Grade C Si Mn P S Cr Mo Ni
42CrMo 0.38-0.45 0.17-0.37 0.5-0.80 ≤0.035 ≤0.035 0.9-1.2 0.15-0.25 -
SCM440 0.38-0.43 0.15-0.35 0.6-0.85 ≤0.035 ≤0.04 0.9-1.2 0.15-0.30 -
42crmo4/1.7225 0.38-0.45 ≤ 0.4 0.6-0.9 ≤0.025 ≤0.035 0.9-1.2 0.15-0.30 -
4140 0.38-0.43 0.15-0.35 0.75-1.00 ≤0.035 ≤0.04 0.8-1.1 0.15-0.25 -
EN19/709M40 0.35-0.45 0.15-0.35 0.5-0.80 ≤0.035 ≤0.035 0.9-1.5 0.2-0.40 -

4: AISI 4140 steel mechanical properties(for guidance only)
Grade Tensile strength
σb(MPa)
Yield strength
σs (MPa)
Elongation
δ5 (%)
Reduction
ψ (%)
Impact Value
Akv (J)
Hardness
4140 ≥1080 ≥930 ≥12 ≥45 ≥63 28-32HRC

5: AISI 4140 steel overviews
Size Round Dia 6-1200mm
Plate/Flat/Block Thickness
6mm-500mm
Width
20mm-1000mm
Heat treatment Normalized ; Annealed ; Quenched ; Tempered
Surface condition Black; Peeled; Polished; Machined; Grinded; Turned; Milled
Delivery condition Forged; Hot rolled; Cold drawn
Test Tensile strength, Yield strength, elongation, area of reduction, impact value, hardness, grain size, ultrasonic test, US inspection, magnetic particle testing, etc.
Payment terms T/T;L/C;/Money gram/ Paypal
Trade terms FOB; CIF; C&F; etc..
Delivery time 30-45 days
Application AISI 4140 steel finds many applications as forgings for the aerospace,oil and gas,automotive, agricultural and defense industries etc.
Typical applications for 4140 steel uses include:forged gears,spindles,fixtures,jigs,collars,Axles,conveyor parts,crow bars,logging parts,shafts,sprockets,studs,pinions,pump shafts, rams, and ring gears etc

6: Delivery condition
For hot forged or hot rolled bar, usually the delivery condition is hot forged or rolled, annealed, rough turned.
For hot forged plate, usually the delivery condition is hot forged, annealed, milled surface.
For hot rolled plate, usually the delivery condition is hot rolled, annealed, black surface.



Hot Rolled SAE4140  Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod 0Hot Rolled SAE4140  Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod 1Hot Rolled SAE4140  Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod 2

Hot Rolled SAE4140  Alloy Steel Round Bar OD 200-600mm SCM440 Forged Solid Rod 3



FAQ
1) why you chose us ?
Because we have large stocks and we have long term cooperative factories.

We can get the lowest ex-factory prices. The price are quite reasonable and it is lower than our commercial peers.

Also, we can guarantee the quality of our products.
2) Our minimum order quantity:
15 Metric Tons
3) How about the Delivery Time?
The steel pipe will be produced since we getting your deposit by T/T or original L/C, and delivery to the port of loading within 25~30 days.
For normal size, some stocks in our factory now, we can shipment within 7~10 days after receive the deposit.
4) What kind of payment does your company support?
T/T, 100% L/C at sight.
5) Do you charge for the samples?
No, we provide samples free, you pay for the freight charge.
6) Main market:
Mid East South America South Asia Africa Southeast Asia Northern Europe Western Europe etc.
