ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm

Sertifika
Çin JIANGSU MITTEL STEEL INDUSTRIAL LIMITED Sertifikalar
Çin JIANGSU MITTEL STEEL INDUSTRIAL LIMITED Sertifikalar
Müşteri yorumları
Bu kalitesi çok iyi .şunu bu firma ile ccooperate devam edecek EUROPURE kalitesi aynıdır, ikinci dereceden l Bu şirketi satın olduğunu.

—— Andrew Greg - Türkiye

200 ton Paslanmaz çelik sac 10 Ekim 2014 tarihinde geldi, kalite çok iyi, teslim süresi çok hızlı Bu fabrikayı bulduğumuz için çok şanslı

—— Mechile Kilar Pazı - Brazial

Yıllarca Bu Fabrikayla İşbirliği Yaptık, Her Şey Çok İyi Gider! Bu Fabrikadan Beğen!

—— Tony Hilton - Polonya

Bu, Mittel'den aldığımız Thrid Zamanımız, Kalite Çok Eşya, Bu Güvenilir Fabrikayı Bulduğumuza sevindik

—— Natalya Ugay-Rusya

Kalite çok iyi ve teslimat süresi çok hızlı, bu firma ile uzun vadeli iş yapmak istiyoruz

—— Pongpol Pluemsati-Tayland

Ben sohbet şimdi

ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm

ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm
ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm

Büyük resim :  ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm

Ürün ayrıntıları:
Menşe yeri: Çin Wuxi
Marka adı: BAO STEEL MITTEL TISCO
Sertifika: SGS ISO MTC
Model numarası: Incoloy 825
Ödeme & teslimat koşulları:
Min sipariş miktarı: Karışık Stiller
Fiyat: 15-26 USD/KG
Ambalaj bilgileri: Ahşap palet kutusu
Teslim süresi: 7 iş günü
Ödeme koşulları: L/C, T/T
Yetenek temini: 80000kgs

ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm

Açıklama
Malzeme: Metal, Paslanmaz Çelik Şekil: Düz
Başvuru: Peyzaj, İç ve dış bahçe dekorasyonu Kullanım: Bahçe Dekorasyonu, çiçek ve bitki ekimi, dış mekan, ofis
Kalınlık: 1-3mm,1.0mm veya Özelleştirilmiş Genişlik: 100-2000mm
Vurgulamak:

ASTM B424 nickel alloy plate

,

Incoloy 825 stainless steel plate

,

UNS N08825 alloy plate 6x1219mm

ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm

Specification And Material Grade Of Incoloy 825 Plate

ASME/ASTM Name ASTM B424 / ASME SB 424
size in mm 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1000 mm x 2000 mm, 2000 mm x 2000 mm, 1500 mm x 3000 mm,
Thickness of Standard Plate 0.1 to 12 mm Thick
Most Frequently Used Form Strip, Flats, Rolls, Ring (Flange), Coils, Foils, Shim Sheet, Blank (Circle), Plain Sheet
Different Finish Cold rolled sheet (CR), 2B, Hot rolled plates (HR), BA NO(8), SATIN (Met with Plastic Coated), 2D,
Hardness Range Half Hard, Soft, Quarter Hard, Spring Hard, Hard etc



Minimum Yield Strength Chart Of Astm B424 UNS N08825 Strip

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
825 8.14 g/cm3 1400 °C (2550 °F) Psi – 80,000 , MPa – 550 Psi – 32,000 , MPa – 220 30 %



Chemical Structure Of 2.4858 Coils

Grade C Mn Si S Cu Fe Ni Cr Al Ti
825 0.05 max 1.00 max 0.5 max 0.03 max 1.50 – 3.00 22.00 min 38.00 – 46.00 19.50 – 23.50 0.02 max 0.06 – 1.20



Equivalent Table Of JIS NCF 825 Plates

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 825 2.4858 N08825 NCF 825 NA 16 ЭП703 NFE30C20DUM NiCr21Mo

ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm 0ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm 1ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm 2 ASTM B424 / ASME SB 424 UNS N08825 Incoloy 825 Nickel Alloy Plate 6*1219mm 3



FAQ

What types of high-temperature alloy products do you offer?
We offer high-temperature alloy rods, wires, strips, plates, tubes, bolts, and nuts. Our products cover various specifications and sizes to meet different application needs.

How to choose the right high-temperature alloy material?
Choosing the right high-temperature alloy material requires a comprehensive consideration of factors such as the temperature, corrosiveness, and mechanical strength requirements of the specific application environment. Our engineers can provide professional advice to help you select the most suitable material.

What international standards do your high-temperature alloy products meet?
Our products meet international standards such as ASTM, AMS, GB/T, ensuring product quality and reliability.

Can you customize products according to customer requirements?
Yes, we offer customized services based on the specific needs of our customers, including special specifications and performance requirements.

What are your production processes and quality control like?
We use advanced production processes and a strict quality control system. From raw material procurement to the final product shipment, every step is carefully monitored to ensure the product quality meets the standards.

Can you provide samples?
Yes, we can provide samples according to your requirements.
